Installation
Item Description Function/information
1 Air cannon ---
1.1 Safety valve loosely enclosed
1.2 Safety rope (not shown) Attach to the structure / loosely enclosed
2 Solenoid valve cabinet Fire the air cannon
2.1 Ball valve with pressure relief hole Locks the air entry and vents all
downstream components
2.2 Check valve Prevents air from leaking out of the system
when a pressure loss occurs
3 Maintenance unit Filter controller with oiler
4 Air line Filling and control line
4.1 Additional filling line
(optional - not recommended)
Additional line for filling, also refer to
Section 3.9 for more information
5 Distributor Fill the air cannon
6 Compressed air supply Min: 3 bar Max: 10 bar
7 Control system (if provided) Electrical control system of the solenoid
valve cabinet
8 Power supply / start signal from higher-level control system
9 Air lines for additional air cannons ---
Tab. 3: Parts list - MARTIN
®
TORNADO air cannon
