Martin Tornado - MARTIN TORNADO 4-Inch Air Cannon

© Martin Engineering GmbH 60 M3727UK-09/15
Part numbers
9.8 MARTIN
®
TORNADO 4-inch air cannon
Fig. 23: Part No. 37798-XXXXXX-XXX+E
*BSP = British Standard Piping
Control port G3/8" BSP /
Steueranschluß
Fill port G3/8" BSP
Füllanschluß
346
TD = Tank diameter /
Behälterdurchmesser
Gesamthöhe
G4"
OH = Overall height /
524
3
7
1
4
6
5
2
