Martin Tornado - Page 62

© Martin Engineering GmbH 61 M3727UK-09/15
Part numbers
ND
Item /
Pos.
Qty. /
Anz.
Description / Beschreibung P/N / Teile-Nr.
1 1 Tornado Valve 4" / Tornadoventil 37797-E+E
2 1 Air cannon tank / Luftkanonenbehälter s.C. / s.T.
31
Safety relief valve G1/2" (10 bar) /
Federsicherheitsventil
s.C. / s.T.
4 1 Safety cable kit / Sicherheitskabelsatz 32271+E
58
HHC screw M16 x 35 - DIN 933, (1.0032) galv. /
Sechskantschraube
41081-16035BZP88
68
Washer flat M16 x 40 x 6 - (DIN522) galv. steel /
Karosseriescheibe
41088-16LZP
78
Washer spring M16 - DIN 127, (1.0032) galv. /
Federring
41090-16AZP
Part number /
Teilenummer
DIM
P/N Item /
Teile Nr. Pos.
TD OH 2
37798-025XXX-XXXX-XXXX+E 350 711 41358-025XX-XXX
37798-050XXX-XXXX-XXXX+E 400 835 41358-050XX-XXX
37798-100XXX-XXXX-XXXX+E 500 1000 41358-100XX-XXX
37798-150XXX-XXXX-XXXX+E 500 1260 41358-150XX-XXX
37798-200XXX-XXXX-XXXX+E 600 1200 41358-200XX-XXX
37798-300XXX-XXXX-XXXX+E 600 1560 41358-300XX-XXX
Part number /
Teilenummer
P/N Item /
Teile Nr. Pos.
3
37798-XXXXXX-DXXX-XXXX+E 21680-10+E
37798-XXXXXX-EXXX-XXXX+E 21680-10E+E
Part number /
Teilenummer
DIM
P/N Item /
Teile Nr. Pos.
TD OH 2
37798-025XXX-XXXX-XXXX+E 350 711 41358-025XX-XXX
37798-050XXX-XXXX-XXXX+E 400 835 41358-050XX-XXX
37798-100XXX-XXXX-XXXX+E 500 1000 41358-100XX-XXX
37798-150XXX-XXXX-XXXX+E 500 1260 41358-150XX-XXX
37798-200XXX-XXXX-XXXX+E 600 1200 41358-200XX-XXX
37798-300XXX-XXXX-XXXX+E 600 1560 41358-300XX-XXX
Part number /
Teilenummer
P/N Item /
Teile Nr. Pos.
3
37798-XXXXXX-DXXX-XXXX+E 21680-10+E
37798-XXXXXX-EXXX-XXXX+E 21680-10E+E
