Martin Tornado - Model-Specific Parts Breakdown

© Martin Engineering GmbH 56 M3727UK-09/15
Part numbers
Part number / Teilenummer
DIM P/N Item / Teile Nr. Pos.
TD OH 4
37853-050XXX-XXXX-XXXX+E 400 966 41358-050XX-XXX
37853-100XXX-XXXX-XXXX+E 500 1129 41358-100XX-XXX
37853-150XXX-XXXX-XXXX+E 500 1389 41358-150XX-XXX
37853-200XXX-XXXX-XXXX+E 600 1329 41358-200XX-XXX
37853-300XXX-XXXX-XXXX+E 600 1689 41358-300XX-XXX
Part number / Teilenummer
P/N Item / Teile Nr. Pos.
5
37853-XXXXXX-DXXX-XXXX+E 21680-10+E
37853-XXXXXX-EXXX-XXXX+E 21680-10E+E
ND
Item /
Pos.
Qty. /
Anz.
Description / Beschreibung P/N / Teile-Nr.
1 1 Adapter flange 4" - 6" / Adapterflansch 36261-190+E
2 1 Tank gasket / Behälterdichtung 36263+E
3 1 Tornado valve 6" / Tornadoventil 37852-E+E
4 1 Air cannon tank / Luftkanonenbehälter s.C. / s.T.
51
Safety relief valve G1/2" (10 bar) /
Federsicherheitsventil
s.C. / s.T.
6 1 Safety cable kit / Sicherheitskabelsatz 32271+E
78
HHC screw M16 x 35 - DIN 933, (1.0032) galv.
/ Sechskantschraube
41081-16035BZP88
88
HHC screw M20 x 50 - DIN 933, (1.0032) galv.
/ Sechskantschraube
41081-20050BZP88
98
Washer flat M20 - DIN 125 B, (1.0032) galv. /
Unterlegscheibe
41088-20BZP
10 8
Washer spring M16 - DIN 127, (1.0032) galv. /
Federring
41090-16AZP
Part number / Teilenummer
DIM P/N Item / Teile Nr. Pos.
TD OH 4
37853-050XXX-XXXX-XXXX+E 400 966 41358-050XX-XXX
37853-100XXX-XXXX-XXXX+E 500 1129 41358-100XX-XXX
37853-150XXX-XXXX-XXXX+E 500 1389 41358-150XX-XXX
37853-200XXX-XXXX-XXXX+E 600 1329 41358-200XX-XXX
37853-300XXX-XXXX-XXXX+E 600 1689 41358-300XX-XXX
ND
Item /
Pos.
Qty. /
Anz.
Description / Beschreibung P/N / Teile-Nr.
1 1 Adapter flange 4" - 6" / Adapterflansch 36261-190+E
2 1 Tank gasket / Behälterdichtung 36263+E
3 1 Tornado valve 6" / Tornadoventil 37852-E+E
4 1 Air cannon tank / Luftkanonenbehälter s.C. / s.T.
51
Safety relief valve G1/2" (10 bar) /
Federsicherheitsventil
s.C. / s.T.
6 1 Safety cable kit / Sicherheitskabelsatz 32271+E
78
HHC screw M16 x 35 - DIN 933, (1.0032) galv.
/ Sechskantschraube
41081-16035BZP88
88
HHC screw M20 x 50 - DIN 933, (1.0032) galv.
/ Sechskantschraube
41081-20050BZP88
98
Washer flat M20 - DIN 125 B, (1.0032) galv. /
Unterlegscheibe
41088-20BZP
10 8
Washer spring M16 - DIN 127, (1.0032) galv. /
Federring
41090-16AZP
Part number / Teilenummer
P/N Item / Teile Nr. Pos.
5
37853-XXXXXX-DXXX-XXXX+E 21680-10+E
37853-XXXXXX-EXXX-XXXX+E 21680-10E+E
