18 Wizard user manual
MC-1
OPERATION
6
The Wizard is fully compatible with the Martin MC-1 controller. This chapter
describes information about how to configure the Wizard for operation with an
MC-1. For further information, refer to the MC-1 user manual.
MC-1 SETTINGS
DIP-switch pin 10 must be set to OFF to enable MC-1 mode operation. Changes
to the setting take effect after the fixture has been turned off and on.
DIP-switch pins 6, 7, 8, and 9 control options that are most useful when operating
multiple Wizards from a single MC-1. When these options are set the fixture will
behave differently compared to other Wizards that do not have these options set.
This is useful if you want to make a light show more diverse.
Option Setting (0 = OFF, 1 = ON)
1234567891011
Use a different color 1 0 1
Use a different gobo 1 0 1
Rotate the mirror drum
in the opposite direction
101
Swivel the mirror drum
in the opposite direction
101
