Martin Wizard - Stand-Alone Settings

Stand-alone operation 17
STAND-ALONE SETTINGS
DIP-switch pins 1-9 enable stand-alone options only when pin 10 is ON. When
pin 10 is off, the DIP-switch selects a DMX address. Pin 11 must be OFF for
stand-alone operation.
The DIP-switch 10 setting takes effect only after the fixture has been turned off
and on.
Note that if the slow movement option is not set then movement will be fast.
Fixture Option Setting (0 = OFF, 1 = ON)
1234567891011
Single or
master
Auto trigger (will
use default
trigger time)
010 0
10
Music trigger
(synchronized
with music)
110 0
Slow movement 1 0 1 0
Slave
Use a different
color in relation to
the master
01
Use a different
gobo in relation
to the master
01
Rotate the mirror
drum in the
opposite direction
to the master
01
Swivel the mirror
drum in the
opposite direction
to the master
01
Mirror drum rotation Mirror drum swivel
