Martin Wizard - Stand-Alone Operation; Single Unit Operation; Master; Slave Operation

Stand-alone operation 15
S TAND - ALONE OPERATION 5
The Wizard may be operated without a controller in stand-alone mode. It can be
operated as a single unit or together with other Wizards in a “master/slave”
configuration.
Several options are available to modify stand-alone operation. These options are
selected using the DIP-switch and are described in this chapter.
Important! The Wizard transmits a signal when DIP-switch pins 2 and 10
are set to ON. To avoid damage to the electronics, connect no
more than 1 transmitting device (master or controller) to the
data link.
SINGLE UNIT OPERATION
The Wizard defaults to stand-alone mode whenever power is applied and there is
no control signal. This can be deactivated by activating 8-channel mode (see
“Setting 6- or 8-channel DMX mode” on page 27).
Options for trigger type, mirror speed and movement direction can be selected as
described under “Stand-alone settings” on page 17.
MASTER / SLAVE OPERATION
Multiple Wizards can be connected together, without a controller, for
synchronized “master/slave” operation in which the slaves mimic, or respond to,
the behavior of the master.
Connecting units for master / slave operation
1 Connect the output of one Wizard to the input of the next Wizard.
2 Connect additional Wizards output to input. Up to 32 may be connected.
3 Terminate the link on both ends by inserting a female termination plug into the data
input of the first fixture and a male termination plug into the data output of the last
fixture. (The female terminator may not be required if the first fixture is the master.)
