MARV User Manual
16
7.
Push the lament into the nozzle until it will go no further (about 5 cm).
Refer to the cross section view of a lament being inserted.
Nozzle
Insertion
hole
Roller
Filament
Caution
Nozzle
Insertion
hole
Roller
Filament
If the lament is not inserted fully, as shown in the cross section above, the lament may not
feed properly and cause the nozzle to clog or printing failure.
8.
Insert the lament fully and push the feeding tube into the insertion hole.
Refer to the cross section view of the feeding tube being inserted.
Nozzle
Insertion hole
Roller
Filament
Feeding
tube
Note
• Printing may not work if the lament is not fully inserted into the nozzle unit.
• If the end of the lament is deformed or bent, cut it cleanly so that it will t into the insertion
hole in the nozzle.
