Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual 2-3
2
system description
CONTROL / INDICATOR DESCRIPTION
6
Display Button
Pressing this button will display the numeric SpCO value
in place of the SpO
2
numeric value and CO in the place of
pulse rate. Pressing this button again will return to the SpO
2
/pulse rate numeric value.
7
Mode / Enter Button
Used to enter the setup menus and to select/activate certain
entries within the menu/setup system.
8
Next Button
Used within the menu/setup system to move through setup
options. Not active during normal patient monitoring.
9
Power On / Off
Press to turn the device on.
Press-and-hold for 2 seconds to turn the device off.
10
Battery Level Indicator
Four LED’s indicate the status of the battery. When the final
indicator begins flashing, replace the batteries.
11
Visual Alarm Indicator
Illuminates when any alarm condition exists. This indicator
may not be turned-off or otherwise over-ridden.
12
%SpO
2
/ %SpCO
Indicator
Indicator above label will illuminate to provide an additional
visual indication of the value currently being displayed.
13
PI
Perfusion Index, or PI, is a relative assessment of the
perfusion at the monitoring site. PI is displayed on a 10
segment LED bar, ranging from < .1% (very weak perfusion)
to >5% (strong perfusion). The highest LED will remain lit
continuously to allow a PI level to be viewed. The Perfusion
Index is the ratio of the AC (pulsatile) to DC (non-pulsatile)
components of the IR (Infrared) signal where the AC and DC
components correspond to the pulsatile and non-pulsatile
amounts of blood, respectively.
14
Low SIQ
Flashes to indicate low SpO
2
Signal IQ. Refer to Section
4, Low Signal IQ.
15
Alarm Silenced Indicator
Flashes to indicate the alarm is temporarily silenced. A solid
illuminated light indicates that the alarms are permanently
silenced until the power is cycled or the alarms are enabled
per Setup Menu 1 in Section 4.
16
Alarm Silence Button
Push once to temporarily silence the alarm for 120 seconds.
Push a second time to return the device to standard alarm
monitoring.
17
Up button
Down button
During saturation monitoring, use these buttons to adjust the
volume of the pulse beep tone.
Within the menu/setup system, these buttons are used to
select values within each menu option.
18
Speaker
Provides audible indication of alarm conditions, pulse tone
and feedback for key-presses. Ensure the speaker is not
covered or the device is placed face-down on bedding or
other sound absorbing surface.
To Next Page
