7-2 Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
7
specifications
Interfering Substances
Carboxyhemoglobin and methemoglobin may erroneously increase oxygen saturation readings. The
level of increase is approximately equal to the amount of carboxyhemoglobin and/or methemoglobin
present. Dyes, or any substance containing dyes, that change usual arterial pigmentation may cause
erroneous readings.
ELECTRICAL
Batteries
Type: 4 “AA” Alkaline
5
Capacity: over 8 hours
4
Isolation: No external power or ground connection, internally powered only, DC current.
ENVIRONMENTAL
Operating Temperature: 0°F to 129°F (-18°C to 54°C)
Transportation/Storage Temperature: -40°F to 158°F (-40°C to +70°C)
5
Operating Humidity: 5% to 95%, non-condensing
Operating Altitude:
500 mbar to 1060 mbar pressure,
-1000 ft to 18,000 ft (-304 m to 5,486 m)
PHYSICAL CHARACTERISTICS
Dimensions: 6.2” x 3.0” x 1.4” (15.8 cm x 7.6cm x 3.6 cm)
Weight: 13oz. (0.37 kg)
SpO
2
Modes
Averaging mode: 2, 4, 8,10, 12, 14 or 16 seconds
6
Sensitivity: Normal, Maximum and APOD
Alarms*
Audible and visual alarms for high low saturation, pulse rate, carboxyhemoglobin and methemoglobin
(SpO
2
range 1-100%, pulse rate range 25-240 bpm, SpCO 5%-40%, SpMet 0.5% - 30%)
Sensor condition, system failure and low battery alarms
High Priority:
571 Hz tone, 5 pulse burst, pulse spacing:
0.250s, 0.250s, 0.500s, 0.250s, repeat time:10s
Low Priority: 500Hz tone, 1 pulse, repeat time: 5s
Volume:
75 dB (max.)
Display/Indicators*
Data display: %SpO
2
, %SpCO, SpCO bar, pulse rate, %SpMet, SpMet bar, PI, PI bar, alarm status,
alarm silenced status, Low Signal IQ, battery status.
Type: LED
Display update rate 1 second
Response time <20 seconds
*See Model Summary for applicable device.
ACCURACY (CONTINUED)
