4-12 Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
4
operation
SETUP MENU LEVEL 4 - TREND SETTINGS (CONTINUED)
NOTE: The date and time must be set before trending will be enabled. The Rad-57 will
automatically ‘time out’ of the setup menu after 10 seconds with no key presses. If the Rad-
57 should time-out of the Trend Settings menu, the trend will not be enabled.
NOTE: Enabling trend (setting Trend to “ON”) will erase all trend information in the Rad-57.
SETUP MENU LEVEL 5 - LED BRIGHTNESS AND FACTORY DEFAULTS
Push the Mode/Enter button again to enter menu level 5.
BUTTON SETTING
5X
LED Display Brightness (4 levels)
NOTE:
All LED indicators are illumi-
nated while adjusting this setting.
Use Up or Down Arrow Keys
to adjust parameter to desired
setting.
Restore Factory Defaults
Pressing a sixth time returns the Rad-57 to patient monitoring display in the
Saturation/Pulse Rate Mode.
MENU SELECTION
SpO
2
and pulse rate will be continuously displayed once the sensor is properly placed and
calibration is complete. To display continuous SpCO, SpMet or PI monitoring (see Model
Summary for applicable device), press
. To return to continuous SpO
2
monitoring and
pulse rate view, press
again.
NOTE: If any parameter breaches its pre-set alarm limit, the Rad-57 will automatically display the
alarming parameter. Pressing Display during an alarm condition will enable the display of other
parameters for 10 seconds. In the event of a multi-parameter alarm condition, the SpO
2
/ Pulse Rate
display will take priority.
POWER OFF
OFF – Press and hold the On/Off button for two seconds.
