2-8 Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
2
system description
Rad-57 Rear Panel (all models)
CONTROL / INDICATOR
DESCRIPTION
Serial Number Label Located on outside of case
Agency Approvals Label Located on outside of case
Battery Cover Located on back of device
Battery Cover Release
Press down and slide the battery cover off the bottom of
the oximeter
AA AA
AA AA
1
2
3
4
1
1
2
3
4
