8-2 Rad-57 Signal Extraction Pulse CO-Oximeter Operator’s Manual
8
Masimo Rainbow
®
Sensors
Masimo Rainbow sensors must be used with the Rad-57 to enable measurement of
Carboxyhemoglobin (SpCO) and Methemoglobin (SpMet). Rainbow sensors will only
function with instruments containing Masimo Rainbow SET Technology or licensed to use
Rainbow compatible sensors.
Rainbow sensors connect to the device directly or with a patient cable.
RAINBOW REUSABLE SENSORS
SpO
2
, SpCO, SpMet and pulse rate accuracy for the Rainbow sensors is specified in the
following table.
Sensor
Weight
Saturation
Accuracy
Pulse Rate
Accuracy
Low Perfusion
Accuracy
SpCO
Accuracy
SpMet
Accuracy
Range
No
Motion
Motion
No
Motion
Motion Saturation
Pulse
Rate
No Motion No Motion
DCI > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3% ± 1%
DCIP 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3% ± 1%
RAINBOW ADHESIVE SENSORS
(Rainbow adhesive sensors must be used in conjunction with Rainbow patient cables)
SpO
2,
SpCO, SpMet and pulse rate accuracy for the Rainbow sensors is specified in the
following table.
Sensor
Weight Saturation Accuracy
Pulse Rate
Accuracy
Low Perfusion
Accuracy
SpCO
Accuracy
SpMet
Accuracy
Range No Motion Motion
No
Motion
Motion Saturation
Pulse
Rate
No
Motion
No
Motion
R25 > 30 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3.5% ± 1%
R25-L > 30 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3.5% ± 1%
R20 3 - 10 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3.5% ± 1%
R20-L
3 - 10 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3.5% ± 1%
10 - 30 kg
60 - 80% ± 3%
70 - 100% ± 2%
± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm ± 3.5% ± 1%
Masimo SpO
2
Sensors
The Rad-57 may also use standard Masimo LNOP, LNOPv and LNCS SpO
2
sensors,
when used with Red PC and LNCS Cables respectively. This will allow the Rad-57 to
work as a Masimo SET pulse oximeter without the carboxyhemoglobin or methemoglobin
measurement.
Select the appropriate patient cable to attach the LNOP, LNOPv or LNCS sensor to the
device.
RED REUSABLE SENSORS
SpO
2
and pulse rate accuracy for the Red sensors is specified in the following table.
Sensor
Weight Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy
Range No Motion Motion No Motion Motion Saturation Pulse Rate
Red DCI > 30 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
Red DCIP 10 - 50 kg ± 2% ± 3% ± 3 bpm ± 5 bpm ± 2% ± 3 bpm
sensors & patient cables
