Masimo Rad-97 Service Manual

Rad-97 Service Manual Chapter 5: Performance Verification Procedures
Masimo Corporation 60 www.masimo.com
2. Power ON the manometer.
• Set the unit of measurement to mmHg.
• Verify the manometer has been calibrated.
3. Power ON the Rad-97.
4. On the Rad-97 home screen, press the Main Menu icon
.
5. Press NIBP
.
6. Press CALIBRATION
.
• For the password, enter 4258.
• Press the Enter key.
7. Press OVERPRESSURE TEST
.
8. To begin the overpressure test, press the Test button, then increase the pressure to the overpressure point:
• Increase pressure to approximately 280mmHg using the hand bulb.
• Very slowly increase the pressure as you approach the overpressure point.
• When the overpressure point is reached, the valves will open (a faint click can be heard when this occurs) and the pressure will rapidly reduce to 0 (zero)
mmHg. Be sure to observe the pressure measurement on the manometer when the valves open.
9. Determine if the NIBP module passed the overpressure test:
• If the valves opened WITHIN the overpressure pass criteria, then the NIBP module PASSED the overpressure test for adults and pediatrics. Go to step 10.
• If the valves opened BEYOND the overpressure point pass criteria, then press the Test button again to confirm the overpressure point. If the valves open
repetitively beyond the pass criteria, contact Masimo Technical Services. See Contacting Masimo on page 65.
10. To stop testing, press Stop.
11. Disconnect the manometer, 500mL bottle or cuff wrapped around solid object, and hand bulb from the NIBP module.
12. Power OFF the manometer.
Test Method for Neonates
1. Follow steps 1 through 3 from Test Method for Adults and Pediatrics above.
Note: If using a cuff, verify the cuff is Neonate. Do not use an Adult or Pediatric cuff for this test method.
2. On the Rad-97 Main Screen, touch the Profiles option in the Status Bar. See About the Status Bar.
3. Select Neonates in the Profiles screen, then touch OK.
4. Start the NIBP measurement then immediately abort:
• Touch the Start NIBP button.
• Touch the Start NIBP button again when then pump starts to inflate the system.
5. Press the Main Menu icon
6. Press NIBP
.
7. Press CALIBRATION
.
• For the password, enter 4258.
• Press the Enter key.
8. Press OVERPRESSURE TEST
.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
