Masimo Rad-97 Service Manual

Masimo Corporation 73 www.masimo.com
Index
A
About This Manual • 7
Alarm Limit Test • 61
Appendix
Rad-97 Component Diagrams • 67
B
Battery Charging • 53
Battery Diagnostics • 53
Battery Installation (Version 1) • 24
Battery Installation (Version 2) • 31
Battery Removal (Version 1) • 20
Battery Removal (Version 2) • 28
Battery Replacement Verification • 53
Battery Test • 53
C
Chapter 1
Maintenance Procedures • 11
Chapter 2
Software Procedures • 13
Chapter 3
Service Procedures • 15
Chapter 4
Electrical Safety Testing • 19, 34, 49
Chapter 5
Performance Verification Procedures • 19, 34, 53
Chapter 6
Troubleshooting and Repair • 63
Chapter 7
Warranty and Service Information • 63, 65
Cleaning • 11, 63, 65
Contacting Masimo • 13, 56, 57, 58, 60, 61, 63, 65
D
Device Classification per IEC-60601-1 • 49
Disassembly • 15, 20, 28, 35, 41
E
Electrical Safety Testing • 49, 63
Electrical Safety Tests • 49
Exclusions • 65
G
Gas Gauge Programming • 28, 34
General • 49
Ground Continuity Test (Class I devices only) • 50
I
Identify Rad-97 Version • 9
L
Limitation of Warranty • 65
Limited Warranty • 65
M
Measuring Earth Leakage Current (Class I devices only) • 50
Measuring Patient Leakage Current • 52
Measuring Touch Leakage Current • 51
N
NIBP Air Leak Test • 57
NIBP Module Calibration Test • 55, 56, 57
NomoLine® Capnography Verification • 61
Noninvasive Blood Pressure Module Tests • 55
Nurse Call Setting Connections • 61
Nurse Call Test • 62, 63
O
Overpressure Test • 59
P
Power-On Self Test • 54
R
Rad-97 - Version 1 • 67
Rad-97 - Version 2 • 70
Rad-97 Battery Replacement • 19
Rad-97 Disassembly and Reassembly - All Versions and Models • 15
Rad-97 TB-20 Connector Replacement • 35
Reassembly • 17, 28, 34, 41, 48
Repair • 63
Repair Policy • 65
Required Tools • 15, 19, 35
Restrictions • 66
Return Procedure • 65
S
Safety Information, Warnings and Cautions • 7
Sales & End-User License Agreement • 66
Service Manual, Rad-97 • 3
Software Upgrade • 13
Software Verification • 13
Span Point Calibration • 56
Supplied Parts List • 19, 35
T
TB-20 Connector Installation (Version 1) • 39
TB-20 Connector Installation (Version 2) • 39, 45
TB-20 Connector Removal (Version 1) • 35
TB-20 Connector Removal (Version 2) • 41
Test Equipment Recommended • 49
Touchscreen Function Test • 54
T
roubleshooting • 63
V
Vent Cleaning • 11
Verification of Electrical Outlet and Power Cable • 49
Z
Zero Point Calibration • 56

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
