34 Radical Signal Extraction Pulse Oximeter Operator’s Manual
4
operation
about
This displays the copyright and software versions of the Handheld and
Docking Station.
output
Note: The output menu selections are only available when the Radical Handheld is
interfaced to the Docking Station.
The following serial output modes are supported. All serial
output is RS-232 based. See the interface specifications in
Section 7, Specifications.
ASCII 1
ASCII text data is sent to the serial interface at one-second
intervals. The ASCII text includes: date and time stamp, SpO
2
pulse rate, PI, and alarm and exception values. All text is single
line followed by a line feed character and a carriage return.
ASCII 2
ASCII text data is sent to the serial interface following a query
from the connecting computer.
HP VUELINK
SpO
2
, pulse rate and plethysmographic waveform data are sent
in HP VueLink format to the serial port.
SPACELABS FLEXPORT
SpO
2
, pulse rate and plethysmographic waveform data are sent
in Spacelabs Flexport format to the serial port.
0%-100%
Scales the saturation measurement with 0% being equal to 0
Volt and 100% equal to 1 Volt.
50%-100%
Scales the saturation measurement with 50% being equal to 0
Volt and 100% equal to 1 Volt.
0V Output
A 0 Volt calibration signal is mapped onto the SpO
2
and pulse
rate analog output. Use this signal for calibration of recording
devices. (0 Volts represents a saturation of 0% and a pulse rate
of 0 bpm).
MENU ITEMS DESCRIPTION
SERIAL MODE
ANALOG
OUTPUT
MODE
