Masimo Radical - Interface and Display Specifications

Radical Signal Extraction Pulse Oximeter Operator’s Manual 49
7
specifications
ENVIRONMENTAL
Operating Temperature: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage Temperature: -40 ° F to 158 ° F (-40 ° C to +70 ° C)
6
Operating Humidity: 5% to 95%, non-condensing
Operating Altitude: 1060 mbar to 500 mbar pressure,
-1000 ft to 18,000 ft (-304 m to 5,486 m)
PHYSICAL CHARACTERISTICS
dimensions
Handheld: 8.9” x 3.3” x 2.1” (22.6 cm x 8.4cm x 5.3 cm)
Standalone: 3.5” x 10.5” x 7.7” (8.9 cm x 26.7cm x 19.6cm)
weight
Handheld: 1.3 lbs. (0.59 kg)
Docking Station (RDS-1, RDS-2, RDS-3): 2.5 lbs. (1.14 kg)
Docking Station (RD-1B, RDS-3B): 4.11 lbs (1.86 kg)
Standalone (RDS-1, RDS-2, RDS-3): 3.8 lbs. (1.73 kg)
Standalone (RDS-1B, RDS-3B): 5.4 lbs. (2.45 kg)
trending
72 hours of trending at 2 second resolution, up to 30 days of trending at 10 second resolution , output
to serial printer or other serial devices
modes
Averaging mode: 2, 4, 8,10, 12, 14 or 16 seconds
7
Sensitivity: Normal and Maximum
8
alarms
Audible and visual alarms for high low saturation and pulse rate (SpO
2
range 1-100%, pulse rate
range 25-240 bpm)
Sensor condition, system failure and low battery alarms
High Priority: 571 Hz tone, 5 pulse burst, pulse spacing: 0.250s,
0.250s, 0.500s, 0.250s, repeat time:10s
Low Priority: 500Hz tone, 1 pulse, repeat time: 5s
Alarm Muted reminder: 500Hz tone, 2 pulse burst, pulse spacing 0.375s, repeat time: 3min.
display/Indicators
Data display: %SpO
2
, pulse rate, pleth waveform, alarm
status, trends, status messages, Signal IQ and perfusion index
Type: Backlit LCD
Pixels: 480 x 160 dots
Dot Pitch: 0.25 mm
output interface
SatShare (RDS-1, RDS-1B),
Serial RS-232, Analog Output, Nurse Call (RDS-1, RDS-1B, RDS-3, RDS-3B)
HP Vuelink, Spacelabs Universal Flexport (RDS-1, RDS-1B, RDS-3, RDS-3B)
