SETTINGS
EN / Mass Combi 12/2500-100; 24/2500-60; 48/2500-35; 48/5000-70 / May 2010 31
6.2 DIP SWITCH B
6.2.1 Power sharing function
See section 3.3.3 for more information.
230V Models DIP switch B
If you want… SW1 SW2 SW3
To limit the AC-input current to 25 Amps. OFF OFF OFF
To limit the AC-input current to 16 Amps. ON OFF OFF
To limit the AC-input current to 10 Amps. OFF ON OFF
To limit the AC-input current to 6 Amps. ON ON OFF
To disable the Power sharing function. --- --- ON
6.2.2 Power Support Function
See section 3.3.5 for more information.
If you want… DIP switch B
SW4
To disable the Power support function OFF
To enable the Power support function ON
6.2.3 Generator / mains support function
See section 3.3.4 for more information.
If you want… DIP switch B
SW5
To disable the Generator / mains support function OFF
To enable the Generator / mains support function ON
6.2.4 Setting for Power Quality at incoming AC
If a generator with distorted output waveform (too low frequency) is used as AC source, the allowed frequency window for the
incoming AC power can be enlarged.
If you want… DIP switch B
SW6
To set the frequency window for the incoming AC power at 45Hz < f < 65Hz OFF
To set the frequency window for the incoming AC power at 35Hz < f < 65Hz ON
CAUTION!
Adjustment of the frequency window at a too low level may cause damage to the connected AC-load. Refer to the
AC-input specifications of the connected loads.
