Mastervolt MASS COMBI 12/2500-100

MASTERBUS
36 May 2010 / Mass Combi 12/2500-100; 24/2500-60; 48/2500-35; 48/5000-70 / EN
Value Meaning Default Adjustable range
DC Voltage Battery voltage (read only)
DC Current Positive value: charge current
Negative value: inverter current
(read only)
AC Input
AC Input Voltage at the AC input of the Mass Combi (read only)
AC Input Input current at the AC input of the Mass Combi (read only)
AC Output
AC Output AC voltage at the Short Break output of the Mass Combi (read only)
AC Output Total AC output current of the Mass Combi (read only)
8.3.2 Configuration
Below parameters can be changed via the MasterBus network by means of a remote control panel or by means of an interface
connected to a PC with MasterAdjust software. See applicable user’s manuals for details.
Value Meaning Default Adjustable. range
Serial interface
Language Language that is displayed on a monitoring device
connected to the MasterBus.
English English, Nederlands,
Deutsch, Français,
Castellano, Italiano,
Norsk, Svenska
Device Model name (Combi 12/250, 24/2500, 48/2500, 48/7000) Model dependent (read only)
Device name Name of this particular device in MasterBus. This name
will be recognized by all devices that are connected to
the MasterBus network.
Mass Combi All names with a
maximum of 16
characters.
Bulk settings
Max. current Maximum output current of the battery charger I-max 0.1A – I-max
Bulk voltage Maximum Bulk voltage 14.40/28.80/57.60V 8-16.00/16-32.00/32-
64.00V
Bulk time Minimum time that the charger stays in Bulk mode 4 min 1-255 min
Bulk return time Delay time before charger switches to Absorption mode
after reaching maximum Bulk voltage
30 sec 1-255 sec
Absorption
Abs. voltage Absorption voltage 14.25/28.50V 8-16.00/16-32.00/32-
64.00V
Max absorp.time Maximum time that the charger stays in absorption mode 360 min 1-65535 min
Min absorp.time Minimum time that the charger stays in absorption mode 45 min 0-255 min
Float settings
Float voltage Float voltage 13.25/26.50/53.0V 8-16.00/16-32.00/32-
64.00V
Forced float vo. Forced float voltage (Constant voltage charging) 13.25/26.50/53.0V 8-16.00/16-32.00/32-
64.00V
Alarm settings
DC Alrm high on Alarm DC High on (see section 3.6) 15.00/31.00/62.00V 8-16.00/16-32.00/32-
64.00V
DC Alrm high off Alarm DC High off (see section 3.6) 14.50/29.50/59.00V 8-16.00/16-32.00/32-
64.00V
DC Alrm low on Alarm DC low on (see section 3.6) 10.00/19.00/38.00V 8-16.00/16-32.00/32-
64.00V
DC Alrm low off Alarm DC low off (see section 3.6) 11.00/22.00/44.00V 8-16.00/16-32.00/32-
64.00V
DC Alrm delay Alarm delay time (see section 3.6) 30 sec 1-255 sec
All error Alarm function will be triggered by all errors Off Off, On
