ORDERING INFORMATION
EN / Mass Combi 12/2500-100; 24/2500-60; 48/2500-35; 48/5000-70 / May 2010 47
11 ORDERING INFORMATION
Part number Description
6384012500 Industrial DC fuse 125A DIN 00
6384512500 Industrial DC fuse 125A DIN 1
6384525000 Industrial DC fuse 250A DIN 1
6384640000 Industrial DC fuse 400A DIN 2
6381001000 Fuse base DIN 00 (max. 160A)
6381002000 Fuse base DIN 1 (max. 250A)
6381003000 Fuse base DIN 2 (max. 400A)
79009006 Battery switch 250A with knob
79009005 Battery switch 250A with key
6502001030 Modular communication cable for connection of remote panels, cross wired, 6 pole, 6 meter / 19 ft
6502100100 Modular communication cable for connection of remote panels, cross wired, 6 pole, 10 meter / 33 ft
6502100150 Modular communication cable for connection of remote panels, cross wired, 6 pole, 15 meter / 49 ft
130010905 Modular communication cable for parallel operation, cross wired, 8 pole, 1 meter / 3 ft
130010906 Modular communication cable for parallel operation, cross wired, 8 pole, 5 meter / 16 ft
130010910 Modular communication cable for parallel operation, cross wired, 8 pole, 10 meter / 33 ft
130010915 Modular communication cable for parallel operation, cross wired, 8 pole, 15 meter / 49 ft
41500500* Battery temperature sensor, incl. 6 meter / 19 ft cable
70405000 Inverter Charger Control (Remote ICC), See section 3.5.1
70405010 AC Power Control Panel (Remote APC) for 230VAC installations, See section 3.5.2
70603250 M-3-R1 Adapter for the mounting of a Remote ICC or APC in a Mastervision panel
70403080 Masterlink MICC, remote control panel for Mass Combi. Features: On/Off, status read out, Power Support,
extended battery monitoring functions See section 3.5.3
77040000 MasterBus terminating device
77040020 MasterBus connection cable (UTP patch cable), 0,2m / 0.6ft
77040050 MasterBus connection cable (UTP patch cable), 0,5m / 1.6ft
77040100 MasterBus connection cable (UTP patch cable), 1,0m / 3.3ft
77040300 MasterBus connection cable (UTP patch cable), 3,0m / 10ft
77040600 MasterBus connection cable (UTP patch cable), 6,0m / 20ft
77041000 MasterBus connection cable (UTP patch cable), 10m / 33ft
77041500 MasterBus connection cable (UTP patch cable), 15m / 49ft
77042500 MasterBus connection cable (UTP patch cable), 25m / 82ft
77050100 100m / 330ft MasterBus cable (UTP cable)
77050200 50 pcs. modular jacks
77050000 Complete set to assemble UTP patch cables. Delivery includes: 100m / 330ft UTP cable, 50 pcs. modular
jacks and crimping tool
77030100 MasterBus – USB interface, required as interface between your PC and the MasterBus when using
MasterAdjust software.
77030400* MasterBus – Serial interface
77010300 MasterView Easy, Touch screen to control and monitor all MasterBus products
77010400 MasterView System, Full-colour touch screen to control and monitor all MasterBus products
77020100 MasterShunt 500, DC-distribution module for exact readout of battery voltage, charge / discharge current,
and state of charge. Continuous rating: 250A, peak current: 500A
* These parts are standard included with the delivery of the Mass Combi 12/2500-100, 24/2500-60, 48/2500-35 and 48/5000-
70
Mastervolt can offer a wide range of products for your electrical installation, including automatic AC transfer switches, remote
control panels and DC distribution kits. See our website www.mastervolt.com for an extensive overview of all our products
