Appendix A: Technical Specifications
System Capacity and Resources:
Vision
206S
Vision
206P
Vision
308S
Vision
308P
Total Ports 8 9 11 12
Trunks (Max.) 2233
Extensions (Max.) 6 7 8 9
Door Phone Port - 1 - 1
Relay Port -1-1
PAS Port - 1 - 1
Comm. Port -1-1
Digital Input Port - 1 - 1
Voice Module - 1 - 1
Speech Paths 7 7 7 7
DTMF Decoders 2 2 2 2
DTMF Encoders 2 2 2 2
Type of Switching : Space Division (CMOS cross point)
Type of Control : CMOS Micro-Controller with SPC
Extension Dialing
A. Pulse Dialing : 10 PPS +/-10%, Make/Break ratio = 1:2
B. DTMF Dialing : As per CCITT recommendation Q.23
Trunk Dialing
A. Pulse Dialing : 10 PPS +/- 5%, make/Break ratio = 1:2 (Break period between 66 to 68 ms),
IDP = 667 ms.
B. DTMF Dialing : As per CCITT recommendation Q.23
Transmission Parameters
Return Loss More than 18 dB
Insertion Loss Less than 1 dB
Inter-channel cross-talk Less than -65 dBm
Idle channel noise Less than -60 dBm
Extension loop resistance 250 ohms max.(excluding telephone)
Power Supply : 90-265VAC, 47-63Hz
Dimensions(LxWxH) : 260 X 75 X 280 mm (10.236 x 2.953 x 11.024 Inch)
Weight : 2.0 kg (4.41 lbs)
Ambient Conditions : 0° to 45°C (32
o
to 113
o
Fahrenheit)
Cabling : 0.5mm single twisted pair
Environment : Temperature: 0° to 45°C (32
o
to 113
o
Fahrenheit)
: Humidity: 95% RH, non-condensing
