27
Matrix
Example: To program telephone number of police i.e. 100 at location code 10. Dial 1301-1-10-100#*. To call
Police station user has to dial 810.
How to program?
Step 1: Make a list of telephone numbers to be stored in global directory.
Step 2: Program the telephone numbers in appropriate part at various locations using command 1301.
Step 3: Clear the numbers from a various locations using command 1301 (if wrongly programmed).
Step 4: Set Trunk Access Group using command 1302.
Step 1
Take a piece of paper and a pen and make a list of telephone numbers.
Step 2
Use following command to program a telephone number in Global Directory list:
1301-1-Location Code-Number-#*
Where,
Location Code is from 10 to 99.
Global Directory part 1 is from 10 to 54.
Global Directory part 2 is from 55 to 99.
Number is the telephone number (maximum 16 digits).
Step 3
Use following command to clear a number in a particular global directory index:
1301-1-Location Code-#*
Where,
Location Code is from 10 to 99.
Use following command to clear the number in all the global directory indexes:
1301-*-#
Step 4
Use following command to set Trunk Access Group for particular location:
1302-1-Location Code-Trunk Access Group
Where,
Location Code is from 10 to 99.
Trunk Access Group is from 0 to 7.
Use following command to set same Trunk Access Group for all locations:
1302-*-Trunk Access Group
Important Points:
• To know programming details, please refer “Configuration Reports”.
• Pause can be entered while storing the telephone number if required. A code ‘#3’ can be used as Pause
digit. Suppose, a string of digits 265 Pause 2556575 is to be stored then it should be programmed as
265#325556575.
Relevant Topics:
1. Class of Service (COS) 70
2. Trunk Parameters 199
3. Alternate Number Dialing 35
4. Trunk Access Groups 189
