Matrix Vision User Manual

Matrix
32
Vision System Manual
Allowed list Number String 00 Number String 01
……
Number String 15
0
Max 16 digits Max 16 digits Max 16 digits
1
Max 16 digits Max 16 digits Max 16 digits
2
Max 16 digits Max 16 digits Max 16 digits
:: : :
7: : :
• A complete denied list would look as below:
Denied list Number String 00 Number String 01
……
Number String 15
0
Max 16 digits Max 16 digits Max 16 digits
1
Max 16 digits Max 16 digits Max 16 digits
2
Max 16 digits Max 16 digits Max 16 digits
:: : :
7: : :
• Default Allowed Lists look as below:
Loc.
List
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
0
BBBBBBBBBBBBBBBB
1
BBBBBBBBBBBBBBBB
2
BBBBBBBBBBBBBBBB
3
BBBBBBBBBBBBBBBB
4
BBBBBBBBBBBBBBBB
5
BBBBBBBBBBBBBBBB
6
BBBBBBBBBBBBBBBB
7
BBBBBBBBBBBBBBBB
• Default Denied Lists look as below:
Loc.
List
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
0
0123456789BBB*#Flash
1
0959896BBBBBBBBB * #Flash
2
09598BBBBBBBBBB * #Flash
3
095BBBBBBBBBBB * #Flash
4
0BBBBBBBBBBBB * #Flash
5
00BBBBBBBBBBBB * #Flash
6
BBBBBBBBBBBBBBB B
7
BBBBBBBBBBBBBBB B
How to program?
Step 1: Take a pen and a paper and decide which number strings are to be programmed in allowed list and the
denied list.
Step 2: Program the number strings in the allowed list using command 1202.
Step 3: Program the number strings in the denied list using command 1204.
Allowed Lists and Denied Lists can be set to default value using command 1201 and 1203.
Take printout of system parameters to know the number string programmed in Allowed Lists and Denied Lists.
Step 1
Take a pen and a paper. Decide which of the above-mentioned three features are to be used. Make the
