Example 2:
Program station 22 (software port number 01) for following constraints:
Disconnect all calls starting with ‘0’ after 240 seconds except calls starting with ‘022’.
Solution:
As observed this type of requirement cannot be met by any of the default CDC tables. Hence, customize CDC
Table 1 and assign it to station 22.
• Program the number ‘0’ in denied list 7 and ‘022’ in allowed list 7. (This step is necessary because default
allowed and denied lists does not contain such as option whereby 022 is available in allowed list and 0 is
available in denied list).
1202-1-7-00-022-#*
1203-1-7-00-0-#*
• Assign this allowed list to CDC table 1.
4915-1-1-7
• Assign this denied list to CDC table 1.
4916-1-1-7
• Assign CDC Timer of 220 seconds (not 240 seconds because 20 seconds are added to CDC Timer for
actual disconnection).
4914-1-1-220
• Other parameters are already available by default hence no need to reprogram them.
• Assign CDC table 1 to station 22.
4920-1-01-1
Important Point:
• It is possible to disconnect specific outgoing calls. For example it is possible to disconnect all calls to
022-28765432 after 180 seconds.
Relevant Topic:
1.
Allowed and Denied Lists 31
