Matrix Vision User Manual

Matrix
82
Vision System Manual
System Parameters as on Tue 07-02-00 at 21:26
--------------------------------------------------------------------------------
Trunk Access Group (TAG)
TAG No : 0 1 2 3 4 5 6 7
TAG Trunks : 012- 0--- 1--- 2--- ---- ---- ---- ----
TAG Rotation : On On On On On On On On
TAG LCR Type : None None None None None None None None
Time Zone LCR Table
Tz No : 0 1 2 3
Tz Start : 00:00 00:00 00:00 00:00
Tz End : 23:59 23:59 23:59 23:59
Tz SP : 0123 0123 0123 0123
Number LCR Table
I Number Sp I Number Sp I Number Sp
0 0123 1 0123 2 0123
3 0123 4 0123 5 0123
6 0123 7 0123 8 0123
9 0123
Mix LCR Table
Tz No : 0 1 2 3
Tz Start : 00:00 00:00 00:00 00:00
Tz End : 23:59 23:59 23:59 23:59
I Number \ Sp :
0 0123 0123 0123 0123
1 0123 0123 0123 0123
2 0123 0123 0123 0123
3 0123 0123 0123 0123
4 0123 0123 0123 0123
5 0123 0123 0123 0123
6 0123 0123 0123 0123
7 0123 0123 0123 0123
8 0123 0123 0123 0123
9 0123 0123 0123 0123
Call Duration Control (CDC) Groups
I Out-Going In-Coming Internal Disconnect OG AL-DL Timer(Sec)
0 Off Off Off No 7 7 160
1 On Off Off Yes 4 4 160
2 On Off Off Yes 2 2 160
3 On Off Off Yes 0 0 160
Relay Port Mode : 1
ON Time Table :
:
:
:
OFF Time Table :
:
:
:
--------------------------------------------------------------------------------
MATRIX VISION Software : V1.5 Page : 2

Matrix Vision Specifications

General

Brand	Matrix
Model	Vision
Category	PBX
Language	English
