19
Calder Brothers Corp
V 1.0
Serial Number Range:
874-S-86TCX5Y2*03874 to _____________
Model: 1860 Paver
3.13 Generator
Toggle generator switch (1) to start/stop generator. The
generators only function is to provide electrical power to
the screed heating system. Go to the digital display to set
screed heat temperature. With generator switch in the on
position, generator will start and stop as needed to maintain
the selected screed heat temperature.
3.14 Match Height
There are two match height switches at each operators
station. Left switch (1) will adjust left hand screed extension,
and right switch (2) will adjust right hand screed extension.
Toggle match height switches to match left and right screed
extensions to center screed height.
3.15 Hopper
Toggle hopper switch (1) to open and close hoppers.
