45
NOTE: Correct any fi t and interference problems before continuing with installation.
CHECKING GAP BETWEEN PLATFORM
AND EXTENSION PLATE
FIG. 45-1
PLATFORM
EXTENSION
PLATE
5/8”
5/8”
8. Raise the platform to vehicle fl oor
level (FIG. 45-1). (Refer to GPT-25,
GPT-3, GPT-4, GPT-5, GPTWR-25,
GPTWR-3, GPTWR-4 & GPTWR-5
OPERATION MANUAL.) Check for
5/8” gap between platform and edge
of extension plate (FIG. 45-1).
STEP 10 - REMOVE LOCKING ANGLES & KNUCKLE
BOLTS, CHECK FOR INTERFERENCE - Continued
