47
STEP 7 - INSTALL CONTROL SWITCH - Continued
POWER DOWN
MODULE
TERMINAL-1
STARTER
SOLENOID
GREEN WIRE
WHITE WIRE
BLACK WIRE
FUSE HOLDER
TERMINAL-2
CONTROL SWITCH CONNECTED TO
PD PUMP ASSEMBLY
FIG. 47-1
