59
2 PLACES
“W”
(TABLE 58-1)
SHIM
(TABLE 51-1)
SHACKLE
(REF)
CENTERED
WELDING SHIMS (RH SHACKLE SHOWN)
FIG. 59-2
SHIM (1/16”, 1/8”, 3/16”, or 1/4”)
MADE FROM STEEL FLAT
FIG. 59-1
2-1/4”
1-1/2”
STEP 12 - PLATFORM ADJUSTMENT (IF REQUIRED)
- Continued
3. Make shims as needed (FIG. 59-1). Position
bottom edge of shim to line up with mark on
shackle (FIG. 59-2). Then, weld the shim to
shackle as shown in FIG. 59-2.
To Next Page
