Configuring Drives (Dual Drive Units Only) 88

Maxtor Central Axis Admin User Guide

Step 13: Slide the cover to lock it into the bottom of the disk drive:

Step 14: Tighten the fastener to hold the unit closed:

Figure 135: Alignment Tabs and Slots

Figure 136: Cover Locked into Bottom of Drive
