MAYEKAWA 4M - Crankshaft Removal and Assembly

Reciprocating Compressor M Series
5-31
5.5.8 Crankshaft
Steps Description
Part
No.
Steps Description
Part
No.
1
Crankshaft
22
Thrust roller bearing (shaft side)
29-1
(Refer to " Removing the Crankshaft".) (Refer to "Assembly of the Thrust Roller
Bearing (Shaft Side)".)
(Refer to "Assembly of the Crankshaft".)
3
Thrust roller bearing (roller)
29-1
1. Remove the parts in the order shown in the figure.
2. Attach the parts in the reverse order of removal.
