M600 Disassembly Instructions
Disassembling the M600 16
12.
Dismantle the floats as follows:
a.
Unfasten one screw connecting the float to the frame, from both sides.
Figure 25: Dismantling the floats (step a)
b.
Remove the floats gently in a circular way
Figure 26: Dismantling the floats (step b)
