Diesel Engines Engine
PID Monitor
• The PID monitor function allows to monitor the PIDs of the PCM with the aid of WDS.
Therefore, select the option ToolboxÆDataloggerÆModulesÆPCM.
Item Definition Unit/Condition
AC_REQ A/C ON request On/Off
ACCS A/C compressor cycling switch On/Off
ALTF Generator field current control duty cycle %
ALTF V Generator output voltage V
APP Accelerator pedal position %
APP_LRN APP learning value - closed V
%
V
%
V
ARPMDES Target idle speed RPM
Pa
V
BOO Brake switch On/Off
BOOST_DSD Boost pressure desired Pa
CATT11_DSD Catalyst temperature desired (upper) °C
CATT12_DSD Catalyst temperature desired (middle) °C
CATT21_DSD Catalyst temperature desired (lower) °C
CHRGLP Generator warning light On/Off
CPP CPP switch On/Off
DEC_CMP Fuel correction for deceleration No unit
DTCCNT DTC count No unit
°C
V
EGR_LRN EGR valve learning value - closed mm
V
mm
%
EQ_RAT11 Equivalence ratio (lambda) No unit
ETC_ACT ISV position actual °
%
°C
EXHPRESS_DIF DPF differential pressure sensor Pa
EXHPRESS_LRN DPF differential pressure sensor learning value Pa
EXHPRESS2 DPF differential pressure sensor (middle) Pa
EXHTEMP1 Exhaust gas temperature sensor (upper) °C
EXHTEMP2 Exhaust gas temperature sensor (middle) °C
EXHTEMP3 Exhaust gas temperature sensor (lower) °C
M6FL_01T016
ETC_DSD ISV position desired
Enabled/
Disabled
ECT ECT sensor
EGRP EGRVP sensor
BARO Barometric pressure sensor
DSC_ACT DSC control
APP1 APP sensor no.1
APP2 APP sensor no.2
01-98 Service Training Mazda6 Facelift
