Body & Accessories Accessories
Wiper / Washer System
• The wiper / washer system is essentially carried over from the previous Mazda6.
• An auto wiper system that detects rainfall on the windshield and automatically controls
all operation (stop, interval, low, and high) has been adopted, removing the burden of
operating switches from the driver.
• The auto wiper system is essentially carried over from the Mazda3 except that there is
now a separate control module, which controls the auto wiper operation as well as the
auto light operation.
• The rain sensor can be adjusted using WDS. This can be necessary after replacing the
windscreen for example.
Auto Wiper System Structural View
M6FL_09036
1
Rain sensor 4 Wiper and washer switch
2 Sensor diode 5 Auto light / wiper control module
3 Windshield
Service Training Mazda6 Facelift 09-61
