Accessories Body & Accessories
PID Monitor
• The PID monitor function allows the PIDs for the Advanced Keyless Entry system to be
monitored. To view these connect WDS to the vehicle and select the option
Toolbox→Datalogger→Modules→RKE.
PID name
(definition)
Data contents
Unit/
Operation
Terminal
DTC_CNT Number of continuous DTCs - -
RPM Engine speed RPM 3Z, 3AA
VSS Vehicle speed KPH 3Z, 3AA
VPWR Supply voltage V 2D
NUMCARD Number of programmed card keys - -
NUMKEY* Number of programmed key ID numbers - -
DRSW_D Door switch (Driver’s door)
OPEN/
CLOSE
2R
DRSW_ALL Door switch (All doors and liftgate)
OPEN/
CLOSE
2R
REQ_SW_D Request switch (Driver’s door) On/Off 3H
REQ_SW_P Request switch (Passenger door) On/Off 3J
REQ_SW_BK Request switch (Trunk lid/Liftgate) On/Off 3L
LOCK_SW_D Door lock-link switch On/Off 3E
IMMOBI Immobilizer system equipped or not On*/Off -
TR/LG_SW Trunk/liftgate latch switch
OPEN/
CLOSE
2R
IG_KEY_IN Key reminder switch
Key-In/
Key-Out
2O
IG_SW_ST Ignition switch (Push switch)
Pushed/
Not Pushed
2N
BUZZER Keyless buzzer On/Off 3Y
PWR_IG1 Power supply (IG1) On/Off 2B
PWR_ACC Power supply (ACC) On/Off 2I
* : Vehicles with immobilizer system
M6FL_09T003
PID/Data Monitor Table
09-40 Service Training Mazda6 Facelift
