Transmission/Transaxle FS5A-EL
A Powertrain mechanism 12 Shift solenoid A, B, C
B Hydraulic pressure control mechanism 13 Oil pump
C Electronic control mechanism 14 TCM
1 Torque converter 15 Oil pressure switch signal
2 Brake clutch 16 Output shaft speed
3
Planetary gear
17 Oil temperature
4 Differential 18 Turbine shaft speed
5 Tire 19 Engine speed
6 Secondary control valve body 20 Throttle position signal
7 Shift solenoid D, E 21 Intermediate shaft speed
8 Primary control valve body 22 Power flow
9 Pressure control solenoid B 23 Hydraulic pressure control signal
10 Shift solenoid F 24 Electronic signal
11 Pressure control solenoid A
Service Training Mazda6 Facelift 05-39
