Engine Diesel Engines
1 Main fuse block 19 Generator
2 Starter relay 20 Fuel pressure sensor
3 Cooling fan relay No.1 21 Glow plug
4 PCM control relay (main relay) 22 MAP sensor
5 Cooling fan relay No.2 23 Fuel injectors
6 A/C relay 24 Refrigerant pressure switch
7 Glow plug relay 25 Temperature correction sensor
8 Exhaust gas temperature sensors 26 DPF differential pressure sensor
9 HO2S 27 PSP switch
10 Neutral switch 28 CMP sensor
11 IAT No.2 sensor 29 VBC solenoid valve
12 CKP sensor 30 Cruise control switch
13 MAF/IAT sensor 31 APP sensor
14 Intake shutter valve position sensor 32 Brake switch
15 EGR valve position sensor 33 Clutch switch
16 ECT sensor 34 PCM (with built-in BARO sensor)
17 Fuel temperature sensor A LHD
18 Suction control valve B RHD
Service Training Mazda6 Facelift 01-81
