Engine Diesel Engines
1 DPF differential pressure sensor 14 A/C relay
2 Temperature correction sensor 15 Glow plug relay
3 Exhaust gas temperature sensor (upper) 16 Glow plugs
4 Exhaust gas temperature sensor (middle) 17 Cooling fan relay No.2
5 Exhaust gas temperature sensor (lower) 18 Cooling fan relay No.1
6 CKP sensor 19 Generator
7 CMP sensor 20 Intake shutter valve
8 APP sensor 21 Intake shutter valve position sensor
9 MAP sensor 22 Intake shutter valve actuator
10 Fuel pressure sensor 23 EGR valve
11 ECT sensor 24 EGR valve position sensor
12 Fuel temperature sensor 25 DC motor
13 Security light 26 PCM
Service Training Mazda6 Facelift 01-83
