3. Installation and Commissioning of SPS-Working Stations
Operating Manual MB-SPS-System
©
GmbH – Version 4.3 - 06/2010
Page 3–9
3.2.5.2 Supply Piping for Vacuum Pump
Disposal Piping for Vacuum Pump Waste Gas:
Use
Connecting the vacuum pump exhaust with the customer’s waste gas disposal
facility (depressurized exhaust outlet).
Material
Optional (length as required):
either: Ø 10 mm reinforced hose and Ø 16 mm hose nozzle
or: Ø 10 mm copper pipe as well as flange and clamp
or: Ø 10 mm stainless steel pipe as well as flange and clamp.
Connection
Type
Hose supply DN 8
3.2.6 Piping Solvent to Glove Box (optional for SPS 800 Manual)
Use
Piping solvent to glove box
Specification
Ø 6 mm stainless steel pipe
Connection
Type
Ø 6 mm tube fitting
3.2.7 Grounding
Use
Potential equalization between system and surrounding
Length
2,5 m
Material
green/yellow 4mm² copper cable
Connection
type
M8 ring type terminal
