25
2.
4.
3.
5.
6.
Figure 2.2 – Other Safety & Instruction Decals
2 Instruction: - Grease every 8
hours
Placed and pointed towards components of the machine which should be
greased at least once every 8 hours
3 Instruction: - Designated lifting
point
Placed at positions on machine where safe lifting should be carried out
SR820 machines are not to be lifted
4 Instruction: - Clutch setting Guidance to the correct process of freeing/setting up driveline clutches
5 Instruction: - P65 cancer and
reproductive harm
Operating, servicing and maintaining this equipment can expose you to
chemicals which are known to the State of California to cause cancer
and birth defects or other reproductive harm.
6 Warning/Instruction: - PTO
operating speed
Indication to the correct operating speed of the machine when in work.
540/1000 RPM
Table 2.2 – Other Safety & Instruction Decal Definitions
For the placement of these decals on each of these machines, please refer to Section 2.5.2.
