55
Please note that not all settings can be achieved on SR620 machines. This is due to the deck design axle
and/or wheel assembly clashing with the wing fabrication, putting potential extreme levels of stress of the
machines axle links.
Figure 4.27 – SR460/620 Cutting Height Adjustment
Height Sleeve
(setting A & B)
A1
275mm
(10 13/16”)*
400mm
(15 ¾”)*
N/A N/A N/A N/A N/A
A2
255mm
(10 1/16”)*
380mm
(14 15/16”)*
N/A N/A N/A N/A N/A
A3
175mm
(6 7/8”)
305mm
(12”)*
N/A N/A N/A N/A N/A
A4
160mm
(6 5/16”)
290mm
(11 7/16”)*
N/A N/A N/A N/A N/A
A5
75mm
(2 15/16”)
210mm
(8 ¼”)
N/A N/A N/A N/A N/A
A6
60mm
(2 3/8”)
190mm
(7 ½”)
N/A N/A N/A N/A N/A
A7 N/A
110mm
(4 5/16”)
N/A N/A N/A N/A N/A
A8 N/A
95mm
(3 ¾”)
N/A N/A N/A N/A N/A
B1 N/A
N/A 75mm
(2 15/16”)
210mm
(8 ¼”)
335mm
(13 3/16”)*
N/A N/A
B2 N/A
N/A 90mm
(3 9/16”)
225mm
(8 7/8”)
350mm
(13 ¾”)*
N/A N/A
B3 N/A
40mm
(1 9/16”)
170mm
(6 11/16”)
305mm
(12”)*
N/A N/A N/A
B4 N/A
55mm
(2 3/16”)
190mm
(7 ½”)
320mm
(12 5/8”)*
N/A N/A N/A
B5 N/A
135mm
(5 5/16”)
270mm
(10 5/8”)*
390mm
(15 3/8”)*
N/A N/A N/A
B6
20mm
(13/16”)
155mm
(6 1/8”)
285mm
(11 ¼”)*
N/A N/A N/A N/A
B7
100mm
(3 15/16”)
235mm
(9 ¼”)
360mm
(14 3/16”)*
N/A N/A N/A N/A
B8
120mm
(4 ¾”)
250mm
(9 13/16”)*
375mm
(14 ¾”)*
N/A N/A N/A N/A
Table 4.3 – SR460/620 Cutting Height Adjustment
NOTE: Setting cannot be achieved on SR620 machines.
