80
Reassembly
Equipment Required
 Phillips head screwdriver
 Flat head screwdriver
 NLGI #2 Molybdenum Disulphide grease with paint brush/distributor
Figur
e
5
.3
1
5.3.4.4 Grease the bearing groove on inner yokes
Figure
5.3
2
5.3.4.5 Fit the bearing ring into the yoke groove with
the grease fitting facing the drive tube
Figure 5.33
5.3.4.6 Install the outer cone, inserting the grease
fitting through the proper hole
Figure 5.34
5.3.4.7 Install the base cone and shield tube
Figure
5.3
5
5.3.4.8 Tighten the Philips head screws. The use of
an electric screwdriver is not recommended
