MCCOY KT5500 - Illustration 2.0.4: Major Component Identification 02

©2008-2017 McCoy Global
Manual № TM12012
80-0420-23 POWER TONG
Section 2
Page 2.6
Description & Specications
2.1 MAJOR COMPONENT IDENTIFICATION (CONTINUED):
Illustration 2.0.4: Major Component Identication 02
13
14
15
16
DESCRIPTIONITEM
TONG HYDRAULIC PRESSURE GAUGE
13
HIGH / LOW GEAR SHIFT LEVER
14
INTERNAL ACCESS PANEL
15
VALVE PACKAGE
16
