MCCOY KT5500 - Illustration 7.16: 101-8715 Latch Opener Assembly; Illustration 7.17: 101-8731 Spring Plunger Assembly

80-0420-23 POWER TONG
Manual № TM12012
Section 7
Page 7.11
©2008-2017 McCoy Global
Parts & Assemblies
Illustration 7.17: 101-8731 Spring Plunger Assembly
Illustration 7.16: 101-8715 Latch Opener Assembly
DESCRIPTION
P/N
QTY.
ITEM
PLATE, LATCH OPENER, KT5500
101-871011
SCREW, SHOULDER, SOCKET HEAD, 3/8, 3/8, STEEL,
GR 8, ZINC
09-907912
SHAFT COLLAR, Ø.875XØ1.625X.5H
02-E045813
2
1
3
DESCRIPTION
P/N
QTY.
ITEM
HOUSING, SPRING
101-873211
PLUNGER ROD, DOOR LATCH
101-873412
SPRING, COMPRESSION
02-E039313
PLATE, LATCH SPRING PLUNGER
101-87331
4
BOLT, HEX, 5/16-18, 1, STEEL, GR 8, ZINC, FULLY
THREADED
09-10263
5
PLUNGER PLUG, DOOR LATCH
101-873516
NUT, HEX, 5/16-18, STEEL, GR 8, ZINC
09-60161
7
1
2
3
6
4
5
7
