MCCOY KT5500 - Illustration 7.9: RIA-KT 5500 Rotary Idler Assembly; Illustration 7.10: CA-KT 5500 Clutch Assembly; Illustration 7.11: PIA-KT 5500 Pinion Idler Assembly

©2008-2017 McCoy Global
Manual № TM12012
80-0420-23 POWER TONG
Section 7
Page 7.8
Parts & Assemblies
DESCRIPTION
P/N
QTY.
ITEM
SHAFT, IDLER
997-D19-11711
GEAR, IDLER, ROTARY
997-A2-11912
SPACER, BEARING
997-D20-12123
SPACER, IDLER
997-D20-1252
4
FITTING, GREASE, 1/8 MNPT
02-00051
5
RETAINER, GEAR
02-000926
METAL SEAL, BALL BEARING
02-00102
7
BEARING, BALL, NSK3212
02-001118
DESCRIPTION
P/N
QTY.
ITEM
SHAFT, CLUTCH
997-A8-5011
CAP, CLUTCH BEARING
997-D11-5412
GEAR, CLUTCH
997-A3-6113
GEAR, LOW CLUTCH
997-A1-521
4
GEAR, HIGH CLUTCH
997-A1-511
5
COLLAR, SHIFTING
997-A9-6216
RETAINER, BEARING CLUTCH SHAFT
997-D11-591
7
BUSHING, CLUTCH
997-6018
RING, EXTERNAL RETAINING, 1.06
02-000119
6306-2RZ02-0002110
BEARING, NEDDLE, B1812
02-0003
4
11
FITTING, GREASE, 1/8 MNPT
02-0005112
FITTING, GREASE, 1/8 NPT 90°
02-0093213
BEARING,DEEP GROOVE BALL, 63205DDU
02-0004114
SPACER, BEARING
1400-54A115
SPACER, BEARING
1400-59A116
3
4
6
7
2
1
4
6 8
3
7
5
9
3
7
16 10
4
6 8
11 11 1 11 11
5
14
15
2
12
13
DESCRIPTION
P/N
QTY.
ITEM
SHAFT, PINION, IDLER
997-D17-10511
GEAR, IDLER, ROTARY
997-A2-11912
RETAINER, BEARING
02-000813
RETAINER, GEAR
02-00092
4
METAL SEAL, BALL BEARING
02-00101
5
BEARING, BALL, NSK3212
02-001116
FITTING, GREASE, 1/8 MNPT
02-00051
7
PAD, PINION, IDLER
1400-10918
5
4
6
4
3
2
1
8
7
Illustration 7.9: RIA-KT 5500 Rotary Idler Assembly
Illustration 7.10: CA-KT 5500 Clutch Assembly
Illustration 7.11: PIA-KT 5500 Pinion Idler Assembly
