MCCOY KT5500 - 2.2 EQUIPMENT SPECIFICATIONS

80-0420-23 POWER TONG
Manual № TM12012
Section 2
Page 2.7
©2008-2017 McCoy Global
Description & Specications
2.2 EQUIPMENT SPECIFICATIONS
Torque Table
Please note that these are ideal values. Actual achieved
torque is highly dependant upon tong efciency and
nal position of rotary gear when full torque load is
reached. Maximum torque is only available in low gear
and full motor displacement.
Pressure
Gear
HI LO
PSI / MPa ft-lbs Nm ft-lbs Nm
1000 / 6.89 1,500 2,033 7,700 10,439
1400 / 9.66 2,300 3,118 11,300 15,320
1800 / 12.41 3,000 4,067 14,900 20,201
2250 / 15.51 3,800 5,152 18,900 25,624
MAXIMUM RATED TORQUE: 18,700 ft-lbs (25,353 Nm)
MAXIMUM SYSTEM PRESSURE: 3000 PSI (20.684 MPa)
Speed Table
Flow
(GPM / LPM)
Low Gear
(RPM)
High Gear
(RPM)
10 / 37.9 3 13.5
20 / 75.7 5.5 27
40 / 151.4 11 54
60 / 227.1 16 81
Maximum Hydraulic Requirements
60 GPM (227.1 LPM)
3000 PSI (20.684 MPa)
Dimensions See page 2.4
Maximum Elevator Diameter Unlimited (tong comes off pipe)
Space Required On Pipe 6.75 in. (17.1 cm)
Torque Handle Length (pipe center to anchor center) 36 in. (91.4 cm)
Dead Weight (approximate) 1250 lbs (568.2 kg)
Gear Reduction Ratio, Turns Encoder Mount to Ring Gear xx:xx:xx
Noise Emissions
A-weighted: 94 dB
C-weighted: 96 dB
Gripping Capacity 2.375 in. (xx cm) through 5.5 in (xx cm)
