MCCOY KT5500 - Illustration 7.8: 101-6054 Door Assembly

80-0420-23 POWER TONG
Manual № TM12012
Section 7
Page 7.7
©2008-2017 McCoy Global
Parts & Assemblies
Illustration 7.8: 101-6054 Door Assembly
DESCRIPTION
P/N
QTY.
ITEM
WELDMENT, DOOR
101-606911
PLATE, LATCH, DOOR
101-871622
BUSHING, DOOR
101-612323
SLEEVE, DOOR SWITCH
101-61241
4
SPACER, DOOR
101-61252
5
BUSHING, DOOR PIVOT
101-789126
SLEEVE, BOTTOM, KT 5500
101-61281
7
TUBE, SPACER, DOOR
101-605818
SLEEVE, DOOR SWITCH
101-614619
BUSHING, BOTTOM, DOOR LATCH SHAFT
101-8148110
BUSHING, TOP, DOOR LATCH SHAFT
101-8147111
SHAFT, LATCH, DOOR
101-8170112
PLATE, DOOR GUARD RETAINER
101-8187113
SPACER, Ø.875 X Ø 1.375 X .125T
02-E0392
4
14
WELDMENT, DOOR HANDLE, KT5500
101-8705115
SPACER, 0.875X1.19X4.22LG
101-8709116
ASSEMBLY, LATCH OPENER, KT5500
101-8715117
PLATE, RUBBER GUARD
101-8717118
KEY STOCK, 1/4 X 1/4 X .50L
101-8718319
ASSEMBLY, SPRING PLUNGER
101-8731120
THRUST BEARING, Ø1.27 X Ø2.0 X .063T
02-E0459121
WASHER, SPRING LOCK, REGULAR, 3/8, 17/25,
0.035-0.125, STEEL, GR 8, ZINC
09-5106122
SCREW, SHOULDER, SOCKET HEAD, 1/2, 1 1/4,
STEEL, GR 8, ZINC
09-0117123
BOLT, HEX, 1/4-20, 2, STEEL, GR 8, ZINC, FULLY
THREADED
09-1015224
BOLT, HEX, 3/8-16, 1 1/4, GR 8, ZINC, FULLY
THREADED
09-1048
5
25
BOLT, HEX, 1/4-20, 1 1/4, GR 8, ZINC, FULLY
THREADED
09-1009226
WASHER, SPRING LOCK, REGULAR, 1/4, 31/64,
0.035-0.125, STEEL, GR 8, ZINC
09-5102
4
27
SCREW, SHOULDER, SOCKET HEAD, 3/8, 3/8,
STEEL, GR 8, ZINC
09-9079128
WASHER, SPRING LOCK, REGULAR, 3/8, 17/25,
0.035-0.125, STEEL, GR 8, ZINC
09-5106
4
29
NUT, NYLOCK, 7/8-9 UNC, SLIM
09-5721230
NUT, JAM, HEX, 3/8-16, STEEL, GR 8, ZINC,
DOUBLE CHAMFER
09-5505
5
31
FITTING, GREASE, 1/4-28, ELBOW
02-9272232
SCREW, SOCKET CAP, SOCKET, 5/16-18, 1 1/4,
GR 8, ZINC
09-2031233
PLATE, DOOR GUARD
101-8840134
32
30
14
2
19
14
11
12
16
24
27
9
6
4
3
31
29
5
25
31
34
25
1
15
21
19
17
10
14
14 2
19
30
32
13
25
18
33
20
26
27
23
8
22
6
7
5
3
28
