MCCOY KT5500 - Illustration 7.13: 101-5998 Shifting Fork Assembly

80-0420-23 POWER TONG
Manual № TM12012
Section 7
Page 7.9
©2008-2017 McCoy Global
Parts & Assemblies
Illustration 7.12: PA-KT 5500 Pinion Assembly
DESCRIPTION
P/N
QTY.
ITEM
CAP, BEARING, PINION
997-D15-8921
GEAR, PINION
997-A7-8612
GEAR, LOW PINION
997-A5-8813
GEAR, HIGH PINION
997-A4-871
4
SPACER, PINION, BEARING
1400-89A2
5
BEARING, DEEP GROOVE BALL, 6307A-2RS
02-000726
FITTING, GREASE, 1/8 NPT 90°
02-0093
4
7
DESCRIPTION
P/N
QTY.
ITEM
WELDMENT, SHIFTING FORK
101-616611
SHAFT, FORK, SHIFTING
101-599912
WASHER, SPRING LOCK, REGULAR, 5/8, 1
5/64, 0.125-0.25, STEEL, GR 8, ZINC
09-511413
NUT, HEX, 5/8-18, STEEL, GR 8, ZINC
09-59141
4
7
1
5
6
4
3
2
5
6
1
7
4
3
2
1
Illustration 7.13: 101-5998 Shifting Fork Assembly
