MCCOY KT5500 - Illustration 7.14: 101-6158 Door Switch Assembly; Illustration 7.15: 101-4092 Pin Backing Assembly

©2008-2017 McCoy Global
Manual № TM12012
80-0420-23 POWER TONG
Section 7
Page 7.10
Parts & Assemblies
Illustration 7.15: 101-4092 Pin Backing Assembly
Illustration 7.14: 101-6158 Door Switch Assembly
DESCRIPTION
P/N
QTY.
ITEM
WELDMENT, GUARD, DOOR SWITCH
101-614111
VALVE, 2 WAY
02-E019012
WASHER, SPRING LOCK, REGULAR, 1/4, 31/64,
0.035-0.125, STEEL, GR 8, ZINC
09-5102
4
3
BOLT, HEX, 1/4-20, 2, STEEL, GR 8, ZINC, FULLY
THREADED
09-1015
44
4
3
2
1
DESCRIPTION
P/N
QTY.
ITEM
PLATE, RETAINER, BACKING PIN
101-409511
PIN, BACKING
101-409412
STUD, 3/8-24, 2
101-409713
SPACER
101-40961
4
SPACER, PIN, BACKING
101-40931
5
KNOB
02-001716
6
4
3
1
2
5
