MCCOY KT5500 - Illustration 7.3: 101-8942 Motor & Gear Assembly; Illustration 7.4: 1050-C-175 Coupling Support Assembly; Illustration 7.5: 101-0071 Hydraulic Support Assembly

©2008-2017 McCoy Global
Manual № TM12012
80-0420-23 POWER TONG
Section 7
Page 7.4
Parts & Assemblies
Illustration 7.3: 101-8942 Motor & Gear Assembly
Illustration 7.4: 1050-C-175 Coupling Support Assembly
Illustration 7.5: 101-0071 Hydraulic Support Assembly
DESCRIPTION
P/N
QTY.
ITEM
MOTOR, HYDRAULIC, RINEER GA 15-13
87-011011
KEY, 5/16 X 5/16 X 1.5"L
01-031712
GEAR, MOTOR
997-A10-14913
BOLT, HEX, 1/2-13, 3/4, GR 8, ZINC, FULLY THREADED
09-91761
4
WASHER, PLAIN, FLAT, WIDE, 1/2, 1 3/8, 0.035-0.125,
STEEL, ZINC
09-50121
5
SCREW, SET, SOCKET, 3/8-16, 3/8, STEEL, GR 8, ZINC,
FLAT POINT
09-010626
DESCRIPTION
P/N
QTY.
ITEM
WELDMENT, COUPLING, INLET
101-113811
PLATE, COUPLING, OUTLET
101-002212
BOLT, HEX, 3/8-16, 1, STEEL, GR 8, ZINC, FULLY THREADED
09-104623
WASHER, TYPE A, FLAT, NARROW, PREFERRED, 3/8, 15/16,
0.035-0.125, STEEL, ZINC
09-51242
4
NUT, HEX, 3/8-16, GR 8
09-58062
5
6
1
2
4
5
3
DESCRIPTION
P/N
QTY.
ITEM
PLATE, SUPPORT, HYDRAULIC
101-002311
PLATE, COUPLING, OUTLET
101-002212
BOLT, HEX, 3/8-16, 1, STEEL, GR 8, ZINC, FULLY THREADED
09-104623
NUT, HEX, 3/8-16, GR 8
09-58062
4
WASHER, PLAIN, FLAT, NARROW, 3/8, STEEL, GR8
09-51242
5
3
2
1
5
4
4
5
1
2
3
